מרכז סיבוב וטחינה של CNC

SPINNER TC 65 MC

turning diameter 310 mm
turning length 600 mm
control Sinumerik 810 D PL Siemens
turning diameter over bed 425 mm
turning speed range - main spindle 500 - 4.500 min/-1
max. Torque 280 Nm
power capacity - main spindel 16,5 kW
Spindle diameter 100 mm
Bedpstqmqhsfx An Eewu
C-Axis 360 °
chucking diameter 210-52 mm
spindle bearing diameter 120 mm
clamping cylinder 65 mm
Bar feed max. 65 / (52) mm
spindle nose A8 DIN 55026
x-axis 230 mm
z-axis 740 mm
rapid traverse X-axis 15 m/min
rapid traverse Z-axis 24 m/min
tool positions turret 12 pos.
driven statition 12 pos.
tool taper VDI 30 DIN 69880
Spindle speed driven tools 6.000 min -1
power capacity - driven tools 3,7 kW
max. Torque 9,5 Nm
dia. of quill MK 4 80 mm
quill stroke 120 mm
tailstock adjustment 475 mm
tension force 500 daN
weight of the machine ca. 4,2 t
dimensions of the machine ca. 3,7 x 2,2 x 1,8 m
CNC - Turning- and Milling Center
SPINNER - TC 65 MC

- Turret completely overhauld
