KNUTH Sinus 330/3000

Technical details:

turning diameter over bed: 330 mm
turning diameter over support: - mm
turning length: 3000 mm
centre height: 330 mm
spindle bore of work spindle: 82 mm
range of revolution per miute: 9 - 1600 U/min
Nlodpfsy Rk S Ejx Ag Dsf
feed range: 0,028 - 6,43 mm/U
tailstock quill adjustment:: 150 mm
tailstock taper MT: MK5
total power requirement: 7,84 kW
weight of the machine ca.: 2,9 t
dimension machine approx.LxWxH: 4,13 x 1,05 x 1,35 m

The KNUTH Sinus 333/3000 is a heavy-duty conventional precision lathe designed for universal industrial applications.
Key strengths of the machine
·Large distance between centers: 3000 mm
·Suitable for machining:
oLong shafts
oHydraulic rods
oRollers
oSpindles
oAxles
oGeneral mechanical engineering components
Equipment
·Sony 3-axis digital readout system (Z0 / Z2 / X)
Accessories
·Various accessories included, see photos.


*
