JENN-WEI JMY-6020

JENN-WEI JMY-6020

This 3s JENN-WEI JMY-6020 horizontal turning machine was manufactured in 2015. It features a maximum turning diameter of 180 mm and a turning length of 300 mm, with a spindle speed of 5,000 rpm. The machine is equipped with a Fanuc Oi-TD control and includes a bar feeder, extraction system, and chip conveyor. If you are looking to get high-quality turning capabilities, consider the JENN-WEI JMY-6020 machine we have for sale. Contact us for further details.

• Max. turning diameter: 180 mm
Fsdpjyir Iwofx Af Rofu
• Max. turning length: 300 mm
• Rapid traverse: X 20 m/min, Z 24 m/min, Y 10 m/min
• Drive: Direct drive on all axes
• A2-6 spindle nose, 60 mm bar bore
• Turret: VDI-30 driven, 20 positions, tool holder 20 mm, round tool 25 mm, 2.2/3.7 kW
• Power-on time: approx. 52,333 hours
• Production run: approx. 900,000 items

Additional equipment

• Bar feeder
• Extraction system
• Chip conveyor
• Green discharge conveyor
