Hyundai HIT-200C + FANUC M-20iA

Hyundai HIT-200C + FANUC M-20iA

This complete automated production cell includes two Hyundai HIT-200C CNC lathes and a FANUC M-20iA industrial robot with a ROBOTOWER automatic loading and unloading system. Each lathe offers a maximum turning diameter of 340 mm and a maximum turning length of 420 mm. The complete cell is designed for automated serial production, especially for larger production batches. Contact us for further details regarding this production cell.

• 2 x Hyundai HIT-200C CNC Lathes
• Year of manufacture: 2003
• CNC control: Siemens Sinumerik
• Maximum turning diameter: 340 mm
• Maximum turning length: 420 mm
• X-axis travel: 240 mm
• Z-axis travel: 430 mm
• Spindle nose: A2-8
• Spindle bore: 80 mm
Nodpfx Ajznm H Rofpeld
• Hydraulic chuck: 10"
• Machine weight: approx. 4,500 kg each
• Rigid and dimensionally stable construction
• Capable of maintaining IT6 tolerance class

Additional Equipment / Automation

• FANUC M-20iA industrial robot, year 2014
• ROBOTOWER automatic loading and finished-part unloading station
• Automatic handling of raw and finished parts
• Set of robot grippers
• Operating manuals
• CE documentation
• Complete production cell suitable for serial production, especially for batches of 500 parts or more
• Robot and loading/unloading system in very good condition
• LOSMA air filtration units (oil mist collectors) visible in the photos is not included in the offer

Technical Specification
Counter Spindle No
Driven Tools No
