DMT ליבת CD480

DMT Kern CD480

Horizontal turning machine manufactured in 2003. This DMT Kern CD480 features a main drive power of 17 kW and a total power requirement of 25 kW. Including tool turret with 12 positions and various VDI30 holders. If you are looking to get high-quality turning capabilities, consider the DMT Kern CD480 machine we have for sale. Contact us for further details.

- Control Unit Model: Heidenhain Manual Plus 4110 (Type: BFT 121 G / LE 412 M) - Voltage / Frequency: 400 V / 50 Hz - Nominal Current: 45 A - Control Voltage: 24 V DC - X-Axis Feed Motor: 4.0 Nm (3000 rpm) - Z-Axis Feed Motor: 6.0 Nm (3000 rpm) - X-Axis Software Limit: -30.50 mm to +235.0 mm - Z-Axis Software Limit: -115.0 mm to +982.0 mm - Operating System / Software: Win98 4.10.2222, IPLC 41HD467

Technical Specification
Counter Spindle No
Driven Tools No
